Pressure switch (pressostat) Fantini Сosmi B12DN
Lead time if the product is out of stock (business days):
27B12/B12..Y pressure switch for over or under pressure Fantini Cosmi
Features:
• Pressure range -0.82...0/0...80 bar
• Changeover contact 250 VAC 16 A
• Sensor material: stainless steel
• Process connection G1/4" internal or external thread
• Medium temperature max. +120 °C
• Protection class IP40/IP65
Typical applications:
• HVAC
• Negative pressure
• Water
Features:
• Pressure range -0.82...0/0...80 bar
• Changeover contact 250 VAC 16 A
• Sensor material: stainless steel
• Process connection G1/4" internal or external thread
• Medium temperature max. +120 °C
• Protection class IP40/IP65
Typical applications:
• HVAC
• Negative pressure
• Water
Series | B12AN |
---|---|
Product type | Pressure switch (pressostat) |
Material (sensor) | Ruostumaton teräs |
Max. pressure (bar) | 18 |
Min. ambient temperature (°C) | -35 |
Max. ambient temperature (°C) | 60 |
Min. measurement range (bar) | 5 |
Max. measurement range (bar) | 16 |
Switching differential | 1...3.5bar |
Process connection | G1/4" |
IP-Class | IP40 |
Brand | Fantini Сosmi |
