Electromagnetic solenoid valve Asco E314K007S1N00FH 1/4"- 230V/50-60Hz
Lead time if the product is out of stock (business days):
36
The ASCO Series 314 is a line of direct acting, general service solenoid valves which can be used as moderate flow pilots for smaller control valves and actuators. With only a spring and two moving parts, the valve is ideal for basic three-way piloting operation It is suitable for analytical and diagnostic equipment, automotive, bottling, dust collector system, and life science applications.
• Compact valve intended for single acting actuator control.
• High operating speed.
• Valve optimised for general 3-way piloting applications, only one spring and two moving parts.
• RoHS compliance.
• Valves do not require a minimum operating pressure.
• The solenoid valves satisfy all relevant EC directives.
• Compact valve intended for single acting actuator control.
• High operating speed.
• Valve optimised for general 3-way piloting applications, only one spring and two moving parts.
• RoHS compliance.
• Valves do not require a minimum operating pressure.
• The solenoid valves satisfy all relevant EC directives.
| Series | E314 |
|---|---|
| Product type | 3/2 solenoid valve |
| Features | 3-way solenoid valve, universal |
| Min. medium temperature (°C) | -15 |
| Max. medium temperature (°C) | 120 |
| Min. pressure (bar) | 0 |
| Max. pressure (bar) | 10 |
| Pipe size | 1/4" |
| Body | E314K007S1N00FH |
| Function | Universal |
| Supply voltage | 230 V/50-60 Hz |
| Material | Brass |
| Sealing material | NBR |
| IP-Class | IP65 |
| Medium | Water, air, oil, inert gases |
| Explosion-proof version | No |
| WRAS | No |
| Manufacturer | ASCO |
| Electrical number | 2826648 |
| Manufacturer code | E314K007S1N00FH |
