Flow valve AVENTICS R412005455
Lead time if the product is out of stock (business days):
35
AVENTICS Series QR1
Shut-off valves are designed for safety-relevant processes. The valves enable manual blocking of air supply, immediately stopping the working stroke.
Shut-off valves are designed for safety-relevant processes. The valves enable manual blocking of air supply, immediately stopping the working stroke.
| Series | QR1 |
|---|---|
| Product type | Flow valve |
| Port 1 | ø6 |
| Port 2 | ø6 |
| Rated current Qn (l/min) | 135 |
| Gas direction | 1 ▶ 2 |
| Compressed air connection type 1 | Push-in fitting |
| Compressed air connection type 2 | Push-in fitting |
| Min. ambient temperature (°C) | 0 |
| Max. ambient temperature (°C) | 60 |
| Min. pressure (bar) | 0.5 |
| Max. pressure (bar) | 10 |
| Delivery unit | 5pieces |
| Material (housing) | Polybutylene terephthalate |
| Material flow control screw | Brass |
| Sealing material | Acrylonitrile butadiene rubber |
| Weight (kg) | 0.028 |
| Brand | AVENTICS |
