Pneumatic 1/4-turn actuator | Double acting | Model PA052DA
Lead time if the product is out of stock (business days):
25
A210 Series Pneumatic Actuators
The A210 series actuators are designed for the automatic operation of valves using compressed air. They are particularly suitable for industrial applications such as process industries, water treatment, and power plants.
Available in double acting and spring return models.
Main features:
Compact and lightweight aluminum body with corrosion-resistant surface treatment
Mounting interfaces compliant with ISO 5211, VDI/VDE 3845, and NAMUR standards
Rack and pinion mechanism for smooth and reliable torque output
Can be operated in both directions: opening and closing with air pressure, or with spring return
Wide torque range and optional travel stops
Technical data:
Operating pressure: 2–8 bar
Operating temperature: -20 °C … +80 °C (wider range available in special versions)
Travel limit adjustment: ±5° in both open and closed positions
Reliable performance even in demanding conditions
Easy installation to valves with standard mounting interfaces
Optional versions include:
Low-temperature design: -40 °C … +80 °C
High-temperature design: -20 °C … +150 °C
The A210 series actuators are designed for the automatic operation of valves using compressed air. They are particularly suitable for industrial applications such as process industries, water treatment, and power plants.
Available in double acting and spring return models.
Main features:
Compact and lightweight aluminum body with corrosion-resistant surface treatment
Mounting interfaces compliant with ISO 5211, VDI/VDE 3845, and NAMUR standards
Rack and pinion mechanism for smooth and reliable torque output
Can be operated in both directions: opening and closing with air pressure, or with spring return
Wide torque range and optional travel stops
Technical data:
Operating pressure: 2–8 bar
Operating temperature: -20 °C … +80 °C (wider range available in special versions)
Travel limit adjustment: ±5° in both open and closed positions
Reliable performance even in demanding conditions
Easy installation to valves with standard mounting interfaces
Optional versions include:
Low-temperature design: -40 °C … +80 °C
High-temperature design: -20 °C … +150 °C
| Series | A210 |
|---|---|
| Product type | Pneumatic 1/4-turn actuator |
| Material (body) | Aluminum |
| Max. pressure (bar) | 8 |
| Min. ambient temperature (°C) | -20 |
| Max. ambient temperature (°C) | 80 |
| Brand | Proval |
| Pneumatic action | Double acting |
| Actuator description | PA052DA |
