Pressure switch (pressostat) Trafag PST4B3.44
Lead time if the product is out of stock (business days):
28
Pressure switch TRAFAG PST4B3.44, adjustment range -0.6...3.4 bar, IP65, max. pressure 12 bar, difference range 0.3 bar, G1/4" internal thread or plate mounting, bellows sensor.
• Sensor material: bronze
• Operating temperature: –40… +85 °C
• Permissible temperature of the medium: –40… +125 °C
• EN175301-803-A with junction box
• AC 250 V 6 (1) A
• DC 24 V 3 (2) A
• DC 220 V 0.25 (0.1) A
• Sensor material: bronze
• Operating temperature: –40… +85 °C
• Permissible temperature of the medium: –40… +125 °C
• EN175301-803-A with junction box
• AC 250 V 6 (1) A
• DC 24 V 3 (2) A
• DC 220 V 0.25 (0.1) A
| Series | PST4B 9B4 |
|---|---|
| Product type | Pressure switch (pressostat) |
| Max. pressure, bar | 12.00 |
| Min. ambient temperature, °C | -40.00 |
| Max. ambient temperature, °C | 125.00 |
| Min. measurement range, bar | -0.60 |
| Max. measurement range, bar | 3.40 |
| Switching differential | 0,3 bar |
| Process connection | Lohko |
| Sensor material | Pronssi |
| IP-Class | IP65 |
| Output signal | 1 vaihtokosketin (SPDT) |
| Manual reset | ei |
| Marine Class | ABS, BV, CCS, DNV-GL, KRS, LR, NKK, RINA, RMRS |
| WRAS | No |
| SIL | No |
| Manufacturer | Trafag |
| HVAC | 4564300 |
| Electrical number | 2729053 |
| Manufacturer code | PST4B3.44 |
