2-phase stepper motor Sanyo Denki ⌀42 mm
Lead time if the product is out of stock (business days):
35Sanyo Denki SanMotion Series F2
• Stepping motors rotate precisely at a fixed angle (step angle). With each pulse the driver receives from a pulse generator.
• Motors typically have a full step angle of 1.8° with 200 steps.
• Used in a wide variety of applications, including fixed-speed drive synchronized with command pulses, accurate positioning, and stable stopping.
Ø 42 mm (Nema 17), Step angle 1,8°. Bipolar.
• Stepping motors rotate precisely at a fixed angle (step angle). With each pulse the driver receives from a pulse generator.
• Motors typically have a full step angle of 1.8° with 200 steps.
• Used in a wide variety of applications, including fixed-speed drive synchronized with command pulses, accurate positioning, and stable stopping.
Ø 42 mm (Nema 17), Step angle 1,8°. Bipolar.
Model | kmm | C | Rated current | Resistance | Inductance | Rotor inertia | Motor length mm | Weight kg | |||
Single shaft | Dual shaft | A | Ω/phase | mH/phase | x10⁻⁴ kg m² | ||||||
103H5205-5040 | -5010 | 5 | 0.23 | 0.25 | 54 | 78 | 0.036 | 33 | 0.22 | ||
103H5205-5140 | -5110 | 5 | 0.25 | 0.5 | 13.4 | 23.4 | |||||
103H5205-5240 | -5210 | 5 | 0.265 | 1 | 3.4 | 6.5 | |||||
103H5208-5040 | -5010 | 5 | 0.35 | 0.25 | 66 | 116 | 0.056 | 39 | 0.3 | ||
103H5208-5140 | -5110 | 5 | 0.38 | 0.5 | 16.5 | 34 | |||||
103H5208-5240 | -5210 | 5 | 0.39 | 1 | 4.1 | 9.5 | |||||
103H5209-5040 | -5010 | 5 | 0.38 | 0.25 | 71.4 | 133 | 0.062 | 41 | 0.31 | ||
103H5209-5140 | -5110 | 5 | 0.41 | 0.5 | 18.2 | 39 | |||||
103H5209-5240 | -5210 | 5 | 0.425 | 1 | 4.4 | 11 | |||||
103H5210-5040 | -5010 | 5 | 0.465 | 0.25 | 80 | 123.3 | 0.074 | 48 | 0.37 | ||
103H5210-5140 | -5110 | 5 | 0.49 | 0.5 | 20 | 35 | |||||
103H5210-5240 | -5210 | 5 | 0.51 | 1 | 4.8 | 9.5 |
Series | F2 |
---|---|
Product type | 2-phase stepper motor |
Max torque (Nm) (possible range) | 0.23 - 0.8 |
Shaft diameter (mm) | 5 |
Frame size (mm) | 42 |
Inertia (x10⁻⁴ kg m²) | 0.036 / 0.056 / 0.062 / 0.074 |
Brand | Sanyo Denki |
